AT06BT
Integrated High-Performance 1D/2D Barcode Scanner with NFC， Professional-Grade Data Acquisition
MediaTek 8781 Octa-Core High-Performance Processor, 6nm Process Technology
5000mAh High-Capacity Removable Battery， Tool-Free Quick Swap Design
Supports 2G/3G/4G Full Netcom, WIFI 6 High-Speed Wireless, and Bluetooth 5.2
Multi-Constellation Satellite Positioning — GPS, BeiDou, Galileo, and More for Global Precision
IP67 Waterproof Rated， 1.5m Drop Resistance， Wide Operating Temperature: -20℃ to 55℃
MediaTek 8781 Octa-Core High-Performance Processor, 6nm Process Technology
5000mAh High-Capacity Removable Battery， Tool-Free Quick Swap Design
Supports 2G/3G/4G Full Netcom, WIFI 6 High-Speed Wireless, and Bluetooth 5.2
Multi-Constellation Satellite Positioning — GPS, BeiDou, Galileo, and More for Global Precision
IP67 Waterproof Rated， 1.5m Drop Resistance， Wide Operating Temperature: -20℃ to 55℃
CPU
MT8781, Octa-core 2.2GHz, 2*A76+6*A55 6nm
RAM
4GB
ROM
64GB
Display Screen
5.99" , IPS, HD+, 720*1440
Touch Panel
INCELL, Multi-point Capacitive
Front Camera
Optional: 8.0MP,FF,F2.4
Rear Camera
13.0MP, PDAF, F2.2
MIC
support
Receiver
support
Noise reduction
support
Audio PA type
support
Motor
support
Speaker
support
G-Sensor
support
Light-Sensor
support
2G/3G/4G
2G：GSM 850/900/1800/1900 3G：WCDMA B1/2/4/5/8 4G：TDD-LTE B34/38/39/40/41 LTE FDD B1/2/3/4/5/7/8/20/28a&b
WiFi
WiFi5,Dual-band(2.4/5.1/5.8GHz),802.11ac/a/b/g/n
BT
5.2 BLE
Location
GPS/Beidou/Galileo/GLONASS/AGPS
Battery
4.4V 5000mAh，Li- polymer, removable
Quick charging
support
RTC
Support
OS
Android 14
USB
support Type-C, USB 2.0 Device，support OTG compatible earphone
Docking charging
support, 5V~2A supports the UC100 universal docking charger
SIM card slot
NanoSIM+NanoSIM/TF
TF card
Up to 1 TB
Dimension
163*77*13.9mm
Weight
265g
Color
Black
NFC
Support, but not standard configuration
Fingerprint
Support, but not standard configuration
1D Scanner
Support
2D Scanner
Support
IP Protection Level
IP67
Drop Test
1.5M
Working Temperature
-20℃~55℃
Storage Temperature
-40℃~70℃
CE
Support
RoHS
Support
UKCA
Support
GMS
Support
UN38.3
Support
CCC
Support
SRRC&CTA
Support
Battery CCC
Support
IP67
Support
Military standard
Support
