AT156I
Intel Core i7-13800H High-Performance Processor
15.6" High-Brightness (500 cd/m²) Sunlight-Readable Display — Enables Continuous Outdoor Operation
Versatile Modular Expansion — RJ45, COM, Thunderbolt, and Custom Mil-Spec Connectors
Supports 4G/5G, WIFI, Bluetooth, and Dual-Mode GPS/BeiDou Positioning
Primary & Secondary Dual-Battery Architecture — Eliminates Power Anxiety in Field Operations and Delivers Extended Runtime
Military-Grade Rugged Protection — Shock-Resistant, Vibration-Resistant, Wide Operating Temperature Range, and Ready for Harsh Environments
15.6" High-Brightness (500 cd/m²) Sunlight-Readable Display — Enables Continuous Outdoor Operation
Versatile Modular Expansion — RJ45, COM, Thunderbolt, and Custom Mil-Spec Connectors
Supports 4G/5G, WIFI, Bluetooth, and Dual-Mode GPS/BeiDou Positioning
Primary & Secondary Dual-Battery Architecture — Eliminates Power Anxiety in Field Operations and Delivers Extended Runtime
Military-Grade Rugged Protection — Shock-Resistant, Vibration-Resistant, Wide Operating Temperature Range, and Ready for Harsh Environments
CPU
Intel® Core™ i7-13800H Processor 24M Cache, up to 5.20 GHz
RAM
16GB/32GB/64GB DDR5
ROM
Optional 128GB/256GB/512GB/1TB
Display Screen
15.6inch，Resolution 1920*1080，Brightness 500cd/㎡,Sunlight Readable
Touch Panel
G+F+F（Capacitive multi-touch screen）
Camera Front Camera
Reserved USB front camera structure position
Voice MIC
Speaker*2, Analog microphone
Sensors G-Sensor
Hall
2G/3G/4G
Supports SIM card and 4G network
WiFi
Support
BT
Support
Location
GPS/BEIDOU
Battery
Main battery capacity：10000mAh Backup battery capacity：2000mAh
Adapter
Input voltage: AC100V~240V, 60/50Hz Output voltage: DC19V, 9.47A
Indicator Light
Power *1 Storage*1 Capslock*1 Battery charging *1
OS
Support for Windows 10 and Windows 11
Port
USB3.0 *3 Power aviation plug*1 RJ45*2 COM*2（Or COM*1+VGA*1） HDMI*1
Dimension
398.35*253.92*46.5mm
Weight
Mg-al material 4.5KG
Color
Brown green
IP Protection Level
Humidity：98％（25℃）
Ruggedization
EMC and ESD meet the requirements of GJB 151B-2013Temperature, damp heat, vibration, impact, drop, salt mist, mold meet the requirements of GJB 322A-98 and GJB 367A-2001
Working Temperature
-20℃~55℃
Storage Temperature
-40℃~70℃
CE
OK
RoHS 2.0
OK
IEC62133
OK
Air and sea survey report
OK
GMS
OK
MSDS
OK
UN38.3
OK
