AT06AT
Integrated High-Performance 1D/2D Barcode Scanner with NFC， Professional-Grade Data Acquisition
6nm MediaTek Dimensity 1080 5G Platform， Octa-Core High Performance
6.52" High-Definition IPS Dewdrop Display with INCELL Multi-Point Capacitive Touch
Supports Global Mainstream 5G/4G Network Bands and WIFI 6 High-Speed Wireless
L1+L5 Dual-Band GPS with Multi-Constellation Support—GPS, BeiDou, Galileo, and More
IP68 Waterproof Rated， 1.5m Drop Resistance， Wide Operating Temperature: -20℃ to 55℃
5G6.52"Android 13IP68MTK8791
CPU
MT8791T，Octa-core 2*2.6GHz A78，6*2.0GHz A55, 6nm
RAM
8GB
ROM
128GB
Display Screen
6.52inch IPS LCD，16:10, HD+, 720*1600
Touch Panel
INCELL multi-point capacitive touch
Front Camera
800W
Rear Camera
1300W，PDAF，F2.2
MIC
support
Receiver
support
Noise reduction
support
Audio PA type
K class
Speaker
support
Motor
support
G-Sensor
OK
Gyro-Sensor
OK
Light-Sensor
OK
P-Sensor
OK
Compass
OK
2G/3G/4G
"2G：GSM B2/3/8 CDMA BC0 3G：WCDMA B1/2/5/8 4G：TDD-LTE B34/39/40/41 LTE FDD B1/3/5/8 5G：NR n1/28A/41/78"
WiFi
"WiFi6，Dual-band（2.4/5GHz） 2 stream 802.11ax/ac/a/b/g/n"
BT
Bluetooth 5.2、3.0+HS、2.1+EDR
Location
"Support L1 GPS/Beidou/Galileo/GLONASS Support L5 GPS/Beidou-III B2A/Galileo-E5a Support AGPS"
Battery
5000mAh（4.4V）
Adapter
PE+ Fast charge 15W fast charge
Indicator Light
support
OS
Android 13
USB
*1，Type-C USB2.0（Support OTG）
DC
support
External expansion port
support
Earphone
"Type C: compatible headset feature 3.5mm Standard earphone"
SIM card
"Slot Type: NanoSIM+NanoSIM/NanoSIM+TF Support dual card requirements"
TF card
Support
Dimension
176.5*79.60*15.30mm
Weight
About 307g (including battery)
Color
Black
NFC
Support
1D/2D Scanner
Support
IP Protection Level
IP68
Drop Test
1.5M
Working Temperature
-20℃~55℃
Storage Temperature
-40℃~70℃
CE
OK
RoHS2.0
OK
IEC62133
OK
Air and sea survey report
OK
IP68
OK
GMS
OK
MSDS
OK
UN38.3
OK
