ATR08AT
Equipped with a Qualcomm SM6225 processor, an 8-core high-efficiency chip; 8-inch high-brightness IPS display, 1000cd/m², visible even in strong sunlight; 10-point touch, Corning Gorilla Glass, durable and robust; 4G+WIFI+Bluetooth 5.2, high-speed and stable; IP67 waterproof tested, drop-proof from 1.2 meters, usable in complex environments; RFID, 1D/2D scanning, fingerprint and NFC, multi-functional professional expansion capabilities.
CPU
MTK 8781, Octa-core，2.2GHz
RAM
8GB
ROM
128GB
Display Screen
8"HD IPS(MIPI) 800*1280, 16:10 portrait screen, Brightness: 1000cd/㎡
Touch Panel
10Points Touch, G+G, Hardness 7H
Front Camera
8MP fixed-focus
Rear Camera
13MP Auto Focus, with flashlight
MIC
*1
Speaker
*2，1.W/8Ω
Motor
*1
G-Sensor
Support
Gyro-Sensor
Support
Compass
Support
Light-Sensor
Support
P-Sensor
Support
Acceleration Sensor
Support
2G/3G/4G/
"GSM: B2/B3/B5/B8 WCDMA: B1/B2/B5/B8 CDMA2000 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28A/B28B,B12/B13/B14/B66/B71 LTE-TDD: B38/B39/B40/B41"
WiFi
WIFI5 802.11(a/b/g/n/ac)
BT
Bluetooth 5.2
Location
GPS、Bei Dou，Galileo、GLONASS
Battery
3.8V 10200Mah
Adapter
5V/3A（DC Port）
OS
Android 16 with GMS
Type-C
*1，Type-C USB3.0 （Support OTG）
USB
*1, USB 2.0
DC
*1，DC 5V/3A
HDMI
*1(mini)
Earphone
*1，3.5mm Standard earphone port
RJ45
*1，RJ45 100/mbps
Pogo pin
Pogo pin*1, 12Pin USB+ Charging
SIM card
*1，Standard Micro SIM Slot
TF card
*1，Max Support 256GB
Dimension
226*145*21.8mm
Color
Black
NFC
13.56MHZ Support:14443A/14443B/15693
Fingerprint
Support
1D Scanner
Support
2D Scanner
Support
IP Protection Level
IP68
Drop Test
1.5M，Laminate floor
Working Temperature
-20℃~60℃
Storage Temperature
-30℃~70℃
CE
Support
3C
Support
RHOS2.0
Support
IEC62133
Support
Air and sea survey report
Support
IP68
Support
GMS
Support
MSDS
Support
UN38.3
Support
