Panel PC RK Series
Supports Rockchip RK3568, RK3576, and RK3588 series processors
On-board 4GB or more of RAM and 32GB eMMC storage
Standard with an HD display and capacitive touchscreen; supports dual displays
Standard with 4 USB ports, LAN, 2 COM ports, and audio ports
1 x Mini-PCIe and 1 x SIM card slot; compatible with 3G, 4G, and 5G modules
VESA mount installation, wall-mounted, and desktop installation
12V or 9–24V wide-range input voltage
Fanless design, patented industrial styling, sleek and elegant
On-board 4GB or more of RAM and 32GB eMMC storage
Standard with an HD display and capacitive touchscreen; supports dual displays
Standard with 4 USB ports, LAN, 2 COM ports, and audio ports
1 x Mini-PCIe and 1 x SIM card slot; compatible with 3G, 4G, and 5G modules
VESA mount installation, wall-mounted, and desktop installation
12V or 9–24V wide-range input voltage
Fanless design, patented industrial styling, sleek and elegant
CPU
RK3568（RK3576/RK3588） quad-core 64-bit Cortex-A55, with a maximum frequency of 2.0GHz
GPU
Mali-G52-2EE（Mali-G52 MC3/Mali-G610 MP4）, Embedded 3D GPU, with built-in high-performance 2D acceleration hardware
NPU
Supports 1T computing power, supports INT8/INT16 hybrid operation （Built-in 6TOPS NPU/Mali-G610 MP4）
Memory
DDR defaults to supporting 2GB, with 4GB optional, and can support up to 8GB
Built-in Storage
The default EMMC is 16GB, expandable up to 256GB.
Playback mode
Supports various playback modes such as loop, scheduled, and interruptible playback.
Network Support
Gigabit and Fast Ethernet, supports WiFi 2.4/BT4.2.4G, wireless peripheral expansion
Function
Supports RTC real-time clock and scheduled power on/off; supports TF card/PC updates; automatically imports screen parameters via TF/USB
